Self-Drilling Lath Screws

Self-Drilling Lath Screws – Product Introduction

Self-Drilling Lath Screws are professional high-strength fasteners specially designed for fixing metal lath, plaster lath, wire mesh and other lath materials to steel studs, wooden studs or concrete substrates. Integrating self-drilling, self-tapping and high-load-bearing functions, they are equipped with a sharp drill point and precision-threaded shank, which can directly drill through metal lath and form tight threads in the base material without pre-drilling. Widely used in building plastering, wall reinforcement, ceiling installation and industrial maintenance projects, these screws are highly trusted by global contractors, construction companies and bulk purchasers for their efficiency, stability and durability.

Core Advantages

Integrated Self-Drilling & Self-Tapping, High Efficiency: The sharp carbide drill point can easily penetrate 0.5-3.0mm metal lath and thin steel studs, and the precision thread completes tapping and fixing in one step. No pre-drilling tools or additional operations are required, which reduces construction steps by 60% and greatly improves work efficiency.
Strong Load-Bearing Capacity, Stable Fastening: The thickened shank and deep thread design enhance the contact area with the base material, providing excellent tensile force and shear force. The screws are not easy to loosen or slip even under long-term load, ensuring the stability of lath fixing and wall reinforcement.
Wear-Resistant & Corrosion-Resistant, Long Service Life: Made of high-quality C1022A medium carbon steel or 304/316 stainless steel, through quenching, tempering and professional surface treatment, the surface hardness reaches HRC48-55, the drill point is wear-resistant and not easy to blunt, and the anti-corrosion performance meets the requirements of indoor and outdoor harsh environments.
Universal Compatibility, Wide Adaptability: Suitable for fixing various lath materials (metal lath, plaster lath, wire mesh, fiber lath) to different substrates (steel studs, wooden studs, light concrete), and compatible with most electric screwdrivers and cordless drills on the global market.
Safe & Reliable, Easy to Operate: The drill point and thread are precisely processed, with smooth feeding during installation, no jamming or breakage. The reasonable head design ensures that the lath is tightly attached to the substrate without damaging the lath surface, avoiding potential safety hazards caused by loose fixing.

Product Classification & Application Scenarios

Screw Type	Drill Point & Thread Feature	Surface Treatment	Application Scenarios
Self-Drilling Lath Screws (Steel Studs)	Sharp carbide drill point, double fine threads, strong engagement	Blue-White Zinc, Color Zinc, Epoxy Coating	Fixing metal lath/plaster lath to light-gauge steel studs, interior wall plastering, ceiling reinforcement
Self-Drilling Lath Screws (Wood Studs)	High-hardness drill point, single coarse thread, fast tapping	Phosphating (Grey), Blue-White Zinc	Fixing wire mesh/fiber lath to wooden studs, residential wall reinforcement, DIY decoration
Stainless Steel Self-Drilling Lath Screws	Corrosion-resistant drill point, fine/coarse thread optional	Natural 304/316 Stainless Steel, Passivation	Outdoor wall plastering, bathroom/kitchen lath fixing, marine and corrosion-prone environments

Key Specifications & Parameters

Parameter	Standard Value	Optional Value	International Standard
Material	C1022A Medium Carbon Steel	304/316 Stainless Steel	ANSI B18.6.4, DIN 7504, GB/T 3098.5
Surface Treatment	Phosphating (Grey), Blue-White Zinc	Color Zinc, Epoxy Coating, Dacromet, Passivation	Salt spray test ≥48h (zinc plating), ≥120h (stainless steel)
Drive Type	PH2 Phillips Slot	Pozidriv Slot, Hex Socket, Torx Slot	Anti-slip, high torque resistance, compatible with global tools
Head Type	Bugle Head, Pan Head	Countersunk Head, Truss Head	Tightly fits lath surface, no protrusion, easy for plastering
Diameter	#6(3.5mm), #8(4.2mm), #10(4.8mm)	#7(3.9mm), #12(5.5mm)	Mainstream export specifications for construction industry
Length	25mm, 35mm, 41mm, 50mm, 63mm	16mm-100mm	Customizable according to lath and substrate thickness
Tensile Strength	≥700MPa	≥900MPa (High-Strength Type)	Meets construction-grade load-bearing requirements
Drilling Capacity	≤2.0mm metal lath + ≤1.2mm steel stud	≤3.0mm metal lath + ≤2.0mm steel stud	No pre-drilling, direct drilling and fixing

Comparison: Self-Drilling Lath Screws vs Ordinary Lath Screws

Comparison Item	Self-Drilling Lath Screws	Ordinary Lath Screws
Installation Requirement	No pre-drilling, self-drilling + self-tapping in one step	Need pre-drilling for metal lath/steel studs, time-consuming
Drilling Capacity	Can drill through metal lath and thin steel studs directly	No drilling capacity, only suitable for pre-drilled holes
Fastening Stability	Deep thread, strong engagement, not easy to loosen	Ordinary thread, loose engagement, easy to slip under load
Construction Efficiency	High, suitable for large-area construction and batch operation	Low, requires additional pre-drilling steps and tools
Applicable Substrates	Steel studs, wooden studs, light concrete, multi-material compatibility	Only suitable for wooden studs or pre-drilled metal substrates

Application Scope

Building plastering projects: Fixing metal lath, plaster lath and wire mesh to steel/wooden studs for wall reinforcement and plastering base.
Interior decoration: Ceiling lath fixing, partition wall reinforcement, decorative panel base installation.
Industrial and commercial construction: Warehouse, workshop, shopping mall wall and ceiling lath installation, fireproof wall reinforcement.
Residential construction: Residential wall plastering, exterior wall insulation lath fixing, balcony and bathroom reinforcement.
Maintenance and renovation: Old building wall reinforcement, lath replacement and maintenance, temporary construction site protection.
DIY and small-scale projects: Home wall decoration, garden fence lath fixing, small shed construction.

Why Choose Our Self-Drilling Lath Screws?

Premium Drill Point & Thread: Adopt high-precision carbide drill point and thread rolling technology, ensuring sharp drilling, smooth tapping, no jamming or breakage, and long service life of the drill point.
Strict Quality Control: Full-process quality monitoring from raw material selection to finished product delivery, ensuring consistent size, uniform hardness, stable performance and no defective products.
Customization Support: We provide OEM/ODM services, supporting customization of diameter, length, surface treatment, head type and packaging to meet the personalized needs of global importers and construction companies.
Export-Oriented Quality: Complies with international construction standards, passes tensile test, shear test and salt spray test, with stable quality and competitive factory price, popular in Europe, America, Australia and Southeast Asia.
Complete Supporting Services: Provide product test reports, quality certificates and customs clearance documents, and provide timely after-sales support for any quality or use problems during construction.
