Hex Washer Head Screws

Hex Washer Head Screws – Product Introduction

Hex Washer Head Screws are high-performance structural fasteners featuring an integrated hex head and washer design, engineered for heavy-duty fastening applications requiring superior clamping force, anti-loosening performance, and easy torque application. The one-piece hex washer head combines the advantages of a hexagonal drive (for high torque transmission) and a built-in washer (for even force distribution), eliminating the need for separate washers and simplifying installation. Crafted with high-quality materials and precision manufacturing processes, these screws are widely used in automotive, machinery, construction, electrical equipment, and industrial assembly, earning high recognition from global manufacturers, contractors, and maintenance professionals for their reliability, durability, and efficiency.

Core Advantages

Integrated Hex Washer Design, Time-Saving & Efficient: The one-piece structure integrates a hex head and a flat washer, eliminating the need to install separate washers during assembly, greatly reducing installation time and labor costs. The built-in washer has a wide bearing surface, which distributes clamping force evenly across the material surface, preventing indentation and damage to soft or thin materials.
Hexagonal Drive, High Torque & Anti-Slip: The hex head design allows for secure engagement with wrenches (socket wrench, open-end wrench) and power tools, enabling high-torque transmission without slipping or stripping. This makes the screws ideal for heavy-duty fastening applications where tight, secure connections are required, even in harsh working environments.
Superior Anti-Loosening Performance: The combination of the hex drive, integrated washer, and precision thread design ensures a tight, stable connection that resists loosening caused by vibration, shock, or long-term use. Suitable for high-vibration equipment (e.g., automotive engines, machinery) and outdoor structural applications.
High Strength & Corrosion Resistance: Made of high-quality C1022A medium carbon steel, 10.9-grade alloy steel, or 304/316 stainless steel, through quenching and tempering heat treatment, the surface hardness reaches HRC45-55, and the tensile strength is up to 800MPa. Available in multiple professional surface treatments, they effectively resist rust, corrosion, and wear, ensuring long service life in indoor, outdoor, and harsh industrial environments.
Versatile Compatibility, Multi-Material Adaptation: Designed for use with a wide range of materials, including metal, wood, plastic, aluminum, and composite materials. Suitable for both indoor and outdoor applications, from light-duty electrical assembly to heavy-duty machinery and construction fastening, meeting diverse industrial needs.

Product Classification & Application Scenarios

Screw Type	Thread & Drive Feature	Surface Treatment	Application Scenarios
Carbon Steel Hex Washer Head Screws	Coarse/fine thread, hex drive, integrated flat washer	Phosphating (Grey), Blue-White Zinc, Electro-Galvanizing	Machinery assembly, electrical equipment, construction, general industrial fastening
Alloy Steel Hex Washer Head Screws	Fine thread, high-torque hex drive, thickened washer	Black Oxide, Zinc Plating, Chromium Plating	Heavy-duty machinery, automotive components, engine assembly, high-vibration equipment
Stainless Steel Hex Washer Head Screws	Coarse/fine thread optional, hex drive, corrosion-resistant washer	Natural 304/316 Stainless Steel, Passivation	Outdoor equipment, marine applications, food machinery, bathroom/kitchen, corrosion-prone environments

Key Specifications & Parameters

Parameter	Standard Value	Optional Value	International Standard
Material	C1022A Medium Carbon Steel	10.9-Grade Alloy Steel, 304/316 Stainless Steel	ANSI B18.2.1, DIN 933, GB/T 5782-2016
Surface Treatment	Phosphating (Grey), Blue-White Zinc	Electro-Galvanizing, Hot-Dip Galvanizing, Black Oxide, Chromium Plating	Salt spray test ≥48h (zinc plating), ≥120h (stainless steel), ≥200h (Dacromet)
Drive Type	Hexagonal Drive (Standard)	Hex Socket Drive, Torx Hex Drive	High torque transmission, anti-slip, compatible with global standard tools
Head Type	Hex Washer Head (Integrated)	Hex Washer Head (Thickened Washer), Countersunk Hex Washer Head	Integrated washer, wide bearing surface, even force distribution
Diameter	M4, M5, M6, M8	M3, M10, M12, M14	Mainstream export specifications for industrial fastening
Length	10mm, 16mm, 20mm, 25mm, 30mm, 40mm	8mm-100mm	Customizable according to fastening thickness and strength requirements
Tensile Strength	≥800MPa	≥1000MPa (High-Strength Alloy Steel Type)	Meets industrial heavy-duty fastening requirements
Thread Type	Coarse Thread (Metric Coarse)	Fine Thread (Metric Fine), Self-Tapping Thread	适配 different material densities, ensuring strong holding power

Comparison: Hex Washer Head Screws vs Hex Head Screws (Without Washer)

Comparison Item	Hex Washer Head Screws	Hex Head Screws (Without Washer)
Head Structure	Integrated hex head + washer, one-piece structure	Independent hex head, no built-in washer
Installation Efficiency	No separate washer needed, fast and efficient installation	Need to install separate washers, time-consuming and labor-intensive
Bearing Capacity	Wide washer surface, even force distribution, no material damage	Narrow bearing surface, easy to indent soft/thin materials
Anti-Loosening Performance	Excellent, integrated structure resists vibration-induced loosening	Good, but relies on separate washers for anti-loosening
Applicable Scenarios	Heavy-duty machinery, automotive, electrical equipment, outdoor construction	General industrial fastening, light-duty assembly, where washers are optional

Application Scope

Automotive industry: Assembly of automotive engines, chassis, body parts, electrical components, and high-vibration equipment.
Machinery manufacturing: Heavy-duty machinery assembly, equipment maintenance, conveyor systems, and industrial machinery fastening.
Construction industry: Steel structure connection, building brackets, outdoor structural fixing, and construction machinery assembly.
Electrical equipment: Assembly of electrical cabinets, transformers, generators, and power distribution equipment.
Marine & outdoor equipment: Outdoor machinery, marine components, and corrosion-prone outdoor structural fastening (stainless steel type).
Industrial assembly: General industrial fastening, tool manufacturing, and equipment base fixing.
DIY & maintenance: Heavy-duty home maintenance, workshop equipment assembly, and large-scale DIY projects.

Why Choose Our Hex Washer Head Screws?

Integrated Design Advantage: The one-piece hex washer head design saves installation time, reduces labor costs, and ensures even force distribution, avoiding material damage and improving fastening stability.
Strict Quality Control: From raw material selection to finished product delivery, we implement full-process quality monitoring, ensuring consistent size, uniform hardness, smooth threads, and no defective products (no breakage, no slip).
Customization Service: We provide OEM/ODM services, supporting customization of diameter, length, thread type, material, surface treatment, and packaging to meet the personalized needs of global importers, manufacturers, and industrial users.
Export-Oriented Standards: Complies with international industrial standards, passes tensile test, shear test, and salt spray test, with stable quality and competitive factory price, popular in Europe, America, Southeast Asia, and the Middle East.
Complete Supporting Services: Provide product test reports, quality certificates, and customs clearance documents, and provide timely after-sales support for any quality or use problems during industrial assembly.
